X1101 - 14' 115k Wishbone (Tangent - Small Angle)
Revision 3
Oct 25, 2016
| Compatible Unit | Description | Qty | MID |
|---|---|---|---|
| X1101 | Bolt, Machine 1/2" x 6" | 4 | 123802 |
| Bolt, Machine 5/8" x 10" | 5 | 124173 | |
| Bolt, Machine 3/4" x 18" | 2 | 124610 | |
| Washer, Galv Double Coil Spring Lock, 1/2" | 4 | 1001444 | |
| Washer, Galv Double Coil Spring Lock, 5/8" | 7 | 1001443 | |
| Washer, Galv Double Coil Spring Lock, 3/4" | 4 | 1001445 | |
| Washer, 1/2" Round | 8 | 196461 | |
| Crossarm, Wood 4-3/4" x 7-1/2" x 14' Precut (Top) | 1 | 873481 | |
| Crossarm, Wood 4-3/4" x 7-1/2" x 14' Precut (Bottom) | 1 | 873499 | |
| Bolt, Shoulder Eye 3/4" x 10" | 2 | 875891 | |
| Swinging Angle Bracket | 1 | 877152 | |
| No. 2 Grid Gain Plate | 2 | 896821 | |
| Crossarm Connection Plate (Bent) | 1 | 896962 | |
| Washer, No. 2 Curved | 2 | 910019 | |
| Washer, Sq 5/8" | 5 | 910267 | |
| Washer, Sq 3" | 5 | 910275 |
